DJI Matrice 30 Specifications
Aircraft.
- Operation Frequency
- 2.4000-2.4835 GHz; 5.725-5.850 GHz
- Transmitter Power (EIRP)
- 2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE) - Hovering Accuracy
- Vertical:'+/-0.1 m (Vision System enabled);'+/-0.5 m (N-mode with GPS);'+/-0.1 m (RTK)
Horizontal:'+/-0.3 m (Vision System enabled);'+/-1.5 m (N-mode with GPS);'+/-0.1 m (RTK) (windless or breezy) - RTK Positioning Accuracy
- 1 cm+1 ppm (horizontal)
1.5 cm+1 ppm (vertical) (fixed RTK enabled) - Max Angular Velocity
- Pitch: 150 Degree /sec.; Yaw: 100 Degree /sec.
- Max Tilt Angle
- 35 Degree (N-mode and Forward Vision System enabled: 25 Degree )
- Max Ascent/Descent Speed
- 6 m/s, 5 m/s
- Max Tilt Descent Speed
- 7 m/s
- Max Horizontal Speed
- 23 m/s
- Max Service Ceiling Above Sea Level
- 5,000 m (with 1671 propellers)
7,000 m (with 1676 propellers) (without other payload) - Max Wind Resistance
- 15 m/s
12 m/s during taking off and landing - Max Hover Time
- 36 min
- Max Flight Time
- 41 min
- Motor Model
- 3511
- Propeller Model
- 1671
1676 High Altitude (not included) - Ingress Protection Rating
- IP55
- GNSS
- GPS+Galileo+BeiDou+GLONASS(GLONASS is supported only when RTK module is enabled)
